Specifications:
1) 800 Watt Power Balcony System
– Deye Solar Micro Inverter 800 Watt
Input Voltage 60V
Output Voltage 230V
Output Current 2.9A/3.8A/4.8A
Output Frequency 50/60 Hz
Output Type Single
Size 212*230*40mm
Type DC/AC Inverters
Inverter Efficiency 96.5%
Certificate IEC/ UL
Warranty 10 years
Weight 3.5kg
Product name solar Micro Inverter
Maximum input DC Voltage 60V
MPPT Voltage Range 25~55V
Operating DC Voltage Range 20~60V
Max. DC Short Circuit Current 16A
Nominal Voltage / Range 230V / 184-265V
Extended Frequency / Range 45~55Hz / 55~65Hz
Power Factor >0.99
Enclosure Environmental Rating IP67
– LONGi Solar Hi-MO5m 54HIB 400W Half-Cut Full Black
Watt 400 Module type Monofacial Framed Number of cells 108 (54)
Watt/m² 205,0 Module surface (m²) 1,953
Cell Half-cut Cell Technology M10 (182mm)
Module efficiency 20,5% Temp. Coef PMAX -0,34%/K
Panel frame color Black
Dimensions 172,2 x 113,4 x 3,0 cm Weight 21,5kg
Cable length 1 200mm – MC4-EVO2 connectors
Junction box Split box – Mid
2) 600 Watt Power Balcony Solar System
– BDM-600-WiFi Micro on grid inverter (Wifi Version)
Recommended Max PV Power (Wp) 450 x 2
Max DC Open Circuit Voltage (Vdc) 60
Max DC Input Current (Adc) 14 x 2
MPPT Tracking Accuracy >99.5%
MPPT Tracking Range (Vdc) 22-55
Isc PV (absolute maximum) (Adc) 18 x 2
Peak AC Output Power (Wp) 550
Dimension: 277x132x50 mm
Grid Code Compliance:VDE -AR-N 4105*
VDE V 0126-1-1/A1
G83/2, CEI 021
AS 4777.2 & AS
4777.3,EN50438
ABNT NBR 16149/1615
Warranty: 10 years
– 330W mono Half Cell PERC solar panel
Pmax:330W
Vmp: 28.63V Voc: 34.6V Imp 11.53A
Size : 15880*1045*35mm ; weight :16kg
Warranty: 12years product and 25years power output
PV Cable: 1.5M*2
Package: 2pcs per carton
3) 400 Watt Balcony Solar System
– LONGi Solar Hi-MO5m 54HIB 400W Half-Cut Full Black
Watt 400 Module type Monofacial Framed Number of cells 108 (54)
Watt/m² 205,0 Module surface (m²) 1,953
Cell Half-cut Cell Technology M10 (182mm)
Module efficiency 20,5% Temp. Coef PMAX -0,34%/K
Panel frame color Black
Dimensions 172,2 x 113,4 x 3,0 cm Weight 21,5kg
Cable length 1 200mm – MC4-EVO2 connectors
Junction box Split box – Mid
– Hoymiles HMS-400 Solar Microinverter
Micro inverter for connection of 1 module
Max. PV power 540 Wp
MPP voltage range 16-60V
Max. input current 14A
Rated output current 400VA
Waterproof IP67
Weight 1,75kg
Dimensions 18.2 × 16.4 × 3 cm
Warranty 12 years
Custom Solar Bracket for all balcony systems
Adjustable slop angel: 15°-30°
Special Horizontal Beam to hang on micro inverter
Material: Allumium alloy + #304 stainess steel
2pcs panels per set
Package: 1set bracket per carton
– 5m 3*1.5mm²ac cable + Fstyle Schuko and connector
250v 16A，IP44, VDE certified
– Inverter Female Protection Cap
– Power Display Socket
